[WT901WIFI] MPU9250 9-axis WiFi wireless sensor, 3-axis Angular Velocity+Acc+Angle+Magnet Field

9-axis WiFi Accelerometer

wt901wifi

• 【Output】The WiFi accelerometer can output Device ID, on-chip time, 3-axis acceleration, angular velocity, magnetic field, angle, temperature, power, signal, version.
• 【Data output rate】The maximum data output rate is 200Hz. The output rate is adjustable from 0.2 to 200Hz.
• 【Internal Integration】The WiFi accelerometer WT901WIFI integrates high-precision gyroscope, accelerometer, and geomagnetic field sensor.
• 【Algorithm Advantages】Adopting self-developed Kalman filter fusion algorithm, it can accurately output the current posture of the module in a dynamic environment.
• 【Wireless use】Built-in lithium battery, working current 80mA, continuous working for 3 hours, charging time 1 hour.
• 【Measurement accuracy】XY axis 0.2°, Z axis 1° (no magnetic field interference).
• 【Package Contents】WT901WIFI inclinometer sensor*1, type-c charging cable*1, quick use guide*1.
• 【Worry-free service】12-month warranty, professional technical support team, quickly and professionally solve any problems you encounter during use.
• 【Application Areas】 VR、Large-scale agricultural automated farming、High-altitude work safety monitoring、Drones, manned aircraft、Industrial posture monitoring、Human motion tracking/capture、Robots, automated guided vehicles、Pedestrian navigation、Unmanned/assisted driving and Military, intelligent weapons and equipment.
